Single Core Cable 3MM

single-core-3-intro

3mm-single-images

Single Core Cable 3mm
Part No. No. Of Cores Cable Dia. (mm) Length (metres) Colour Amps Conductor
cross
section
(mm2)		 Strand No./Dia. NZ Ref.
5813-30BK 1 3mm 30 Black 10
(20*)		 1.13 14/0.32 150
5813-100BK 1 3mm 100 Black 10
(20*)		 1.13 14/0.32 150
5813-30RD 1 3mm 30 Red 10
(20*)		 1.13 14/0.32 150
5813-100RD 1 3mm 100 Red 10
(20*)		 1.13 14/0.32 150
5813-30GN 1 3mm 30 Green 10
(20*)		 1.13 14/0.32 150
5813-100GN 1 3mm 100 Green 10
(20*)		 1.13 14/0.32 150
5813-30YW 1 3mm 30 Yellow 10
(20*)		 1.13 14/0.32 150
5813-100YW 1 3mm 100 Yellow 10
(20*)		 1.13 14/0.32 150
5813-30BE 1 3mm 30 Blue 10
(20*)		 1.13 14/0.32 150
5813-100BE 1 3mm 100 Blue 10
(20*)		 1.13 14/0.32 150
5813-30WE 1 3mm 30 White 10
(20*)		 1.13 14/0.32 150
5813-100WE 1 3mm 100 White 10
(20*)		 1.13 14/0.32 150
5813-30BN 1 3mm 30 Brown 10
(20*)		 1.13 14/0.32 150
5813-100BN 1 3mm 100 Brown 10
(20*)		 1.13 14/0.32 150
5813-30OE 1 3mm 30 Orange 10
(20*)		 1.13 14/0.32 150
5813-100OE 1 3mm 100 Orange 10
(20*)		 1.13 14/0.32 150
5813-30VT 1 3mm 30 Violet 10
(20*)		 1.13 14/0.32 150
5813-100VT 1 3mm 100 Violet 10
(20*)		 1.13 14/0.32 150
5813-30PK 1 3mm 30 Pink 10
(20*)		 1.13 14/0.32 150
5813-100PK 1 3mm 100 Pink 10
(20*)		 1.13 14/0.32 150
5813-30GY 1 3mm 30 Grey 10
(20*)		 1.13 14/0.32 150
5813-100GY 1 3mm 100 Grey 10
(20*)		 1.13 14/0.32 150
3mm-tracer-images

Single Core Cable 3mm with Tracer
Part No. No. Of Cores Cable Dia. (mm) Length (metres) Colour Amps Conductor
cross
section
(mm2)		 Strand No./Dia. NZ Ref.
5813-30T1 1 3mm 30 Black with
White Tracer		 10
(20*)		 1.13 14/0.32 150
5813-30T2 1 3mm 30 Red with
Black Tracer		 10
(20*)		 1.13 14/0.32 150
5813-30T3 1 3mm 30 Green with
White Tracer		 10
(20*)		 1.13 14/0.32 150
5813-30T4 1 3mm 30 Yellow with
Blue Tracer		 10
(20*)		 1.13 14/0.32 150
5813-30T5 1 3mm 30 Blue with
White Tracer		 10
(20*)		 1.13 14/0.32 150
5813-30T6 1 3mm 30 White with
Brown Tracer		 10
(20*)		 1.13 14/0.32 150
5813-30T7 1 3mm 30 Brown with
White Tracer		 10
(20*)		 1.13 14/0.32 150
